JOY E-BIKE
E-Monster Specifications
- BATTERY TYPE
- SUSPENSION
- SPEED
- RANGE
- BRAKES
- WHEELS
- COLOR OPTIONS
- DIMENSIONS
- DRIVE MOTOR
BATTERY TYPE
| Batter Type | 72 V, 40 AH, Lithium Ion Fixed Type |
|---|---|
| Charging Time | 5 to 5.5 hours |
SUSPENSION
| Suspension type | Hydraulic |
|---|---|
| Front Side suspension | Upside Down Fork |
| Rear Side suspension | Monoshock |
SPEED
| Top Speed | 60 KMph* |
|---|
RANGE
| Range Per Full Charge | 100 Kms* |
|---|
BRAKES
| Front brake | Disc |
|---|---|
| Rear brake | Disc |
WHEELS
| Wheels Type | Alloy Wheels |
|---|---|
| Wheels Size | 14 inch |
| Tyre Type | Tubeless |
| Front Tyre | 120/70-12 |
| Rear Tyre | 130/70-12 |
COLOR OPTIONS
| Color Options | Black, Red and White |
|---|
DIMENSIONS
| Kerb Weight | 100 kgs |
|---|---|
| Gross Weight | 195 kgs |
| Ground Clearance | 150 mm |
| Turning Radius | 1.6 m |
| Noise level (dB) | < 50 |
| Dimensions (L) | 1780 mm |
| Dimensions (W) | 1030 mm |
| Dimensions (H) | 775 mm |
DRIVE MOTOR
| Drive Motor | 1500 Watts, DC brushless Hub Motor |
|---|
JOY E-BIKE
Monster Specifications
- BATTERY TYPE
- SUSPENSION
- SPEED
- RANGE
- BRAKES
- WHEELS
- COLOR OPTIONS
- DIMENSIONS
- DRIVE MOTOR
BATTERY TYPE
| Batter Type | 74 V, 25Ah / 30 Ah, Lithium Ion |
|---|---|
| Charging Time | 4 To 4.5 hours |
SUSPENSION
| Suspension type | Hydraulic |
|---|---|
| Front Side suspension | Twin Fork |
| Rear Side suspension | Monoshock |
SPEED
| Top Speed | 25 kmph |
|---|
RANGE
| Range Per Full Charge | 75 kms* |
|---|
BRAKES
| Front brake | Disc |
|---|---|
| Rear brake | Disc |
WHEELS
| Wheels Type | Alloy Wheels |
|---|---|
| Wheels Size | 14 inch |
| Tyre Type | Tubeless |
COLOR OPTIONS
| Color Options | Black, Red and White |
|---|
DIMENSIONS
| Kerb Weight | 75 kgs |
|---|---|
| Gross Weight | 195 kgs |
| Ground Clearance | 110 mm |
| Turning Radius | 1.6 m |
| Noise level (dB) | < 50 |
| Dimensions (L) | 1460 mm |
| Dimensions (W) | 610 mm |
| Dimensions (H) | 1070 mm |
DRIVE MOTOR
| Drive Motor | Drive motor 250 Watts High Performance Brushless DC Hub motor |
|---|---|
| Rated RPM of the hub motor | 100 – 375 |
JOY E-BIKE
Glob Specifications
- BATTERY TYPE
- SUSPENSION
- SPEED
- RANGE
- BRAKES
- WHEELS
- DIMENSIONS
- DRIVE MOTOR
BATTERY TYPE
| Batter Type | 60 V / 23 Ah, Lithium Ion Or Lithium Iron |
|---|---|
| Charging Time | 3.5 hrs. (with regular charger) 2.5 hrs. (with opt. fast charger) |
SUSPENSION
| Suspension type | Hydraulic |
|---|---|
| Front Side suspension | Telescopic Fork type |
| Rear Side suspension | Dual adjustable shock absorbers |
SPEED
| Top Speed | 25 kmph |
|---|
RANGE
| Range Per Full Charge | 70 Kms* |
|---|
BRAKES
| Braking | Front/Rear Side Drum Brake |
|---|
WHEELS
| Wheels Type | Alloy Wheels |
|---|
DIMENSIONS
| Kerb Weight | 67 kgs |
|---|---|
| Dimensions (L) | 1800 mm |
| Dimensions (W) | 460 mm |
| Dimensions (H) | 1100 mm |
DRIVE MOTOR
| Drive Motor | 250 Watts BLDC Motor (Waterproof) |
|---|
JOY E-BIKE
Wolf Specifications
- BATTERY TYPE
- SUSPENSION
- SPEED
- RANGE
- BRAKES
- WHEELS
- DIMENSIONS
- DRIVE MOTOR
BATTERY TYPE
| Batter Type | 60 V / 23 Ah, Lithium Ion Or Lithium Iron |
|---|---|
| Charging Time | 3.5 hrs. (with regular charger) 2.5 hrs. (with opt. fast charger) |
SUSPENSION
| Suspension type | Hydraulic |
|---|---|
| Front Side suspension | Telescopic Fork type |
| Rear Side suspension | Dual adjustable shock absorbers |
SPEED
| Top Speed | 25 kmph |
|---|
RANGE
| Range Per Full Charge | 70 Kms* |
|---|
BRAKES
| Braking | Front/Rear Side Drum Brake |
|---|
WHEELS
| Wheels Type | Alloy Wheels |
|---|
DIMENSIONS
| Kerb Weight | 67 kgs |
|---|---|
| Dimensions (L) | 1800 mm |
| Dimensions (W) | 460 mm |
| Dimensions (H) | 1100 mm |
DRIVE MOTOR
| Drive Motor | 250 Watts BLDC Motor (Waterproof) |
|---|
JOY E-BIKE
Gen Nxt Specifications
- BATTERY TYPE
- SUSPENSION
- SPEED
- RANGE
- BRAKES
- WHEELS
- DIMENSIONS
- DRIVE MOTOR
BATTERY TYPE
| Batter Type | 60 V / 23 Ah, Lithium Ion Or Lithium Iron |
|---|---|
| Charging Time | 3.5 hrs. (with regular charger) 2.5 hrs. (with opt. fast charger) |
SUSPENSION
| Suspension type | Hydraulic |
|---|---|
| Front Side suspension | Telescopic Fork type |
| Rear Side suspension | Dual adjustable shock absorbers |
SPEED
| Top Speed | 25 kmph |
|---|
RANGE
| Range Per Full Charge | 70 Kms* |
|---|
BRAKES
| Braking | Front/Rear Side Drum Brake |
|---|
WHEELS
| Wheels Type | Alloy Wheels |
|---|
DIMENSIONS
| Kerb Weight | 67 kgs |
|---|---|
| Dimensions (L) | 1800 mm |
| Dimensions (W) | 460 mm |
| Dimensions (H) | 1100 mm |
DRIVE MOTOR
| Drive Motor | 250 Watts BLDC Motor (Waterproof) |
|---|
